Specifications
1. top quality and long working life.
2. gasoline power tillers from 6.5hp, 7hp.
3. OEM serivce offered.
4. fast delivery.
gasoline tillers:? 6.5hp and 7 hp.
diesel cultivators: 178f diesel power tiller, 186f diesel power tiller.
Tilling scope (mm):??? 750mm
Tilling depth (mm)? 150-300mm
Tillage efficiency (m2/h) 500-800
Type of drive: engine-triangle belt-chain wheel and chain-Gear shift: 1,0.2
Primary clutch types: belt tensioning type
Oil capacity (L):? 0.95
Direction adjustment of armrest: screw-bolt-locke ( adjustble up and down)
Specifications of walking wheel: 350-6
Wheel track (mm): 370mm
Width of axle (mm): 200-Shape of axle: hexagonal axle ( opposite sides are 23mm)
Starting system: recoil
Engine :? 168f
Engine type: single cylinder, 4-stroke, oHV.
Bore* stroke: ( mm)??? 68* 54 -Displacement: 196cc
Rated output power: KW(PH)??? 4.78/6.5
Engine speed:?? 3600rpm
Fuel comsumption (g/kw.h):? <= 395
Fuel type: automotive unleaded gasoline
Fuel tank capacity: 3.5L
Lube capacity: 0.6L
Dimensions: (L*W*H): 1400*840*1020
Net weight: 60kg
