Specifications
1. Professional manufacturer of rotary tillers.
2.side gear transmission
3.heavy type,high quality
4.hot selling
Detailed Product Description
1GL series rotary tiller with side gear transmission,it can be mounted with the tractor 12-50 hp.We can't see the wheel tracks on the soil after it worked. The quality of the rotary tiller is good and the function very well. it is suited to dry land and paddy field. it can save time, labour and money etc. strong point.
Heavy rotary tiller
|
Model
|
1
|
2
|
3
|
4
|
5
|
|
Dimensions(L*W*H)
|
1250*800*700mm
|
1450*800*700mm
|
1550*800*700mm
|
1700*800*700mm
|
2000*800*700mm
|
|
Weight
|
265 kg
|
285 kg
|
300 kg
|
320 kg
|
350 kg
|
|
Nb.of blades
|
24
|
30
|
30
|
36
|
42
|
|
Working width
|
1045mm
|
1245mm
|
1345mm
|
1495mm
|
1795mm
|
|
Working depth
|
120mm
|
120mm
|
120mm
|
120mm
|
120mm
|
|
PTO Input speed
|
540r/min
|
540r/min
|
540r/min
|
540r/min
|
540r/min
|
|
Power required
|
20-30 HP
|
25-35 HP
|
30-40 HP
|
30-50 HP
|
40-75 HP
|
|
