APPLICATIONS:
Rotary Cultivator Tiller are designed to suit every kind of soil for preparing fine seed beds for root crops, orchards, fodder crops and cash crops etc. only in one or two passes. It enhances the soil fertility by mixing the residue of crops like Cotton, Sugarcane, and Wheat etc. It can be applied in dry and wet soil and can be used for puddling.
FEATURES:
Specially designed L- Blades, having a longer life & requires less maintenance.
Side chain drive .
PTO shaft with shear bolt system, to avoid damage to Rotary Tiller & Tractor due to overload.
Tilling depth can be controlled by depth skid from 8 cm to 12 cm in all the models.
Spring loaded adjustable trailing board.
Technical Date:
|
Tractor
|
Power
|
15-25HP
|
18-25HP
|
20-30HP
|
20-30HP
|
25-35HP
|
30-40HP
|
|
Type of Linkage
|
Three-Point Hitch Linkage
|
|
Speed of PTO (r/min)
|
540
|
|
Tillage Width (cm)
|
85
|
95
|
105
|
115
|
125
|
135
|
|
Tillage Depth (cm)
|
8-12
|
8-12
|
8-12
|
8-12
|
8-12
|
8-12
|
|
Speed of Cultivator shaft (r/min)
|
210
|
210
|
210
|
210
|
210
|
210
|
|
Number of Blade (pieces)
|
16
|
16
|
20
|
24
|
28
|
32
|
|
Net Weight (kg)
|
96
|
108
|
116
|
129
|
132
|
142
|
|
