Conventional or Centrally Located Seed Hoppers available with conventional seed hoppers each holding
1.9 bushels or the Air Seed Delivery (ASD) uses two centrally-mounted seed hoppers capable of holding a total of 110 bushels.
Seed Metering Options mechanical or EdgeVac vacuum seed metering available on conventional planters, ASD equipped planters are mechanical only.
Hydraulic Telescoping Tongue a hydraulically operated tongue section with an adjustable iron swivel hitch
accommodates various single or dual tractor tire arrangements.
Low-Profile, Triple-Folding Row Markers equipped with 16 diameter solid marker blades with depth bands.
A hydraulic sequence valve with flow control alternates the markers automatically, or allows both to be
lowered at the same time.
Convenient, Precision-Cut, Plated Sprockets mounted above easy access transmissions at the end of each wing.
Contact Drive System spring-loaded contact drive tires eliminate mechanical clutches and smooth the engagement and disengagement of the drive helping to reduce residue, rock and mud problems.
Half-Width Planting shut off either side of the planter with 12VDC point row clutches, activated from the cab-installed control console.
Complete Electric/Hydraulic Control row markers, point row clutches and the folding/unfolding functions are all controlled from the seat of your tractor.
