Features:
1. This walking rice transplanter has used high powered gasoline engine so that it has a high working reliability;
2. by using precise cutting and slicing technology, it guarantees uniformity of transplanting rice seedlings;
3. by using functions of automatic removing congestion and automatic profiling and hydraulic lifting device, it guarantees consistent depth of the rice seedlings transplanted;
4. Since the hydraulic system uses pump and valve integrated construction, the whole machine is compact in structure and light in weight, with good performance of paddy field passing ability;
5. With a left and right balancing function (TBS hydraulic system), it has improved its adaptability of operating, which takes the lead in China.
Technical Parameters:
|
Type
|
Two wheels, three floating plates type
|
|
Walking Wheel
|
Rubber tire needle driving wheel
|
|
Length*Width*Height(mm)
|
2460*1480*860(980)
|
|
Weight(kg)
|
175
|
|
Engine Name
|
B&S 93400 (American)
|
|
Engine Power(hp/rpm)
|
3.5/3600
|
|
Variable Speed
|
Forewords two gears, backwards one gear
|
|
Productivity
|
0.13-0.26(ha./h)
|
|
Working speed
|
0.31-1.10m/s
|
|
Working Rows
|
4rows
|
|
Rows Spacing (mm)
|
300(fixed)
|
|
Seeding Distance (mm)
|
223
|
200
|
180
|
146
|
130
|
117
|
|
