1. Matched drive Dongfeng 12-18hp working tractor
2 .Use forcorn/ beans/ rice / wheat
3. breadth (mm) 1200
4. Working depth (mm) 30~80
5. Sowing depth (mm) 30~50
6. Fertilization depth (mm) 50~70
7. Blade type IIIS150
8. Total number of knives 48
9. The form to connect with the tractor direct connected
10. Working speed (km/h) 1~3
11 .The speed of the arbor (r/min) 512
12 .weight (kg) 145
13 .external dimensions(L*W*H) (mm) 985*1380*680
14 .fuel consumption (kg/hm2) 10~12(Reference Ranges)
15 .seeding unit number: 6
Displacement and adjustment means Side spiral adjusts
16 .fertilizer apparatus Number: 6
Displacement and adjustment means Side spiral adjusts
17 .furrow opener Number: 6
The spectrum of the adjustment of depth (mm) 0~50
18 .fertilizing amount (Kg/ hm2) 0~500
19 .Sowing amount(Kg/ hm2) 0-450(Rice / Wheat)
