Detailed Product Description
LOADING:
20'FT:  108  PCS
40'FT:  230  PCS
40'HQ:  230  PCS
Body size:1800×1350×850
Net/gross weight: 105/115kg
Tilling width (mm): 1,100
Tilling depth (mm): 150-300
Gear shifting: -1, 1, 2
Driving model: gears
Transmission oil capacity(L): 1.1
Engine model: KAMA186F (diesel engine)
Displacement (mL): 406
Max. Power 10hp/ 3,600rpm
Rated power: 9hp/ 3,600rpm
Minimum oil consumption (g/KW. h):290
Air cleaner model: oil bath, foam filter element
Combustion system: direction injection
Fuel tank capacity(L): 5.5
Engine type: single-cylinder, vertical four-stroke, forced air-cooled engine
Starting system: recoil/ electric start
Shaft: horizontal
Dimension (mm):1050×570×780
Certifications: CE
