Specifications
1.Wheel Self-propelled type
2.Harvesting width 2360mm
3.Productivity 0.2-0.5 hec/h
Product Description:
1.main specification
|
Structure Type
|
Self-propelled
|
|
Feed Rate
|
2.6 kg/s
|
|
Harvesting Width
|
2360 mm
|
|
Total Weight
|
4300 kg
|
|
Overall Dimensions (L×W×H)
|
6123 ×2927 ×3200 mm
|
|
Engine Power
|
58 kw
|
|
Driving Wheel Distance
|
1.7m
|
|
Grain tank
|
1.3CBM
|
2. Favorable Performance:
(1.The king-sized water tank radiator is favorable for long-time harvesting operations,and newly designed cab,lower noise,smaller vibration,better seal and beautiful appearance.
(2.The new kind of cleaning mechanism guarantees high cleanliness of the seeds.
(3.The composite instruments and multipurpose warning system are strong in their operationality.
(4.The enlarged grain unloading port reduces the supporting grain unloading time, thus enhancing the operational efficiency.
(5.Use of Interchangeable header can fulfill many functions and increase working hours.Stable performance and good suitability
(6.Self-propelled type, improved assembly of clutches, convenient maintenance and higher output, reasonable structure obtains convenient operation.
(7.Lower loss rate, more function and lower price.
(8.Angle adjustable, conforms to human factors engineering and easy operated.Driving structure of shaker, convenient maintenance and high reliability.
(9.Stepless speed-adjustment of reel, non-stop of machine during Operation, rotate speed can be adjusted according to requirements and increase productivity.
(10.Optimized bridge, the driver can get more exact position of crops and feed will be more equally.
(11.Thicker live axle and additional bearing lubrication oil cup, completely solve lubrication problems and increace Lifespan
|
