Specifications

Size:4800*1900*1700mm
Roller length: 2000mm
Under the roller speed: 450-500 rotate/minuter
Productivity:1500-2500kg/hour
total loss rate: 2.5%
Containing impurities:1.5%
Fitted Power (hp):12-28HP Tractors
Weight:1380KG
The wheat and rice threshing
light weight,
easy to installation,
operation and maintenance,
Maize thresher ,maize peeling machine
1,is widely used types of threshing equipment,
2,with small size, light weight,
3,easy to installation, operation and  maintenance,
4,high production efficiency advantages.

Note:
1, to seriously and carefully before use and maintenance. Before the wheat harvest, must be carefully checked in advance of the thresher, repair, view the bolt is loose, profile bar is intact, if there are problems such as transmission components. Insecurity and resolved to find out, must not let thresher with "disease" operation.The use of power, whether diesel or electric motors should be test run in advance to ensure foolproof.
2, thresher common purpose and reason.
(1) threshing gap is too large, rotary speed is too low, etc.;
(2) separation is unclear: a common cause of insufficient wind or the wind wrong, thresher sieve damage or gap is too large, too wet grain logic equation; unique visitors into the grain uneven, wet and so had done.
(3) drum block: reasons and because feed grain is too wet, too big, roller speed over lower stalk damage caused by tooth winding drum, power shortage or voltage is too low, etc.;
(4) Broken grain: The reason is threshing gap is too small, the drum speed is too high, feed grains uneven, wet and so had done;
(5) drum murmur: pattern rod bolts loose, concave deformation, threshing small gap;
(6) motor overheating: feeding causes excessive load is too large, poor ventilation, heat dispersion is not out, low voltage or wire substandard.
