Specifications
Speedy Drying,Premium Quality,Min Cost
Drying Medium:Hot wind
Dry Agri-products like paddy,wheat,maize
Burn paddy hull etc
1. designed for high quality packaging design career with drying machine, you can create maximum profit
2. and forced more dispersed device and material circulation quantitatively rotary valve, let the seed dry grain evenly
3. using large screw feeder, large steel, stainless steel sheet, though the long-term use of resistance
4. and efficient exhaust fan, full open dry, dry speed and high efficiency
Equipped with the furnace, wrap or other hull pledge material such as born abandoned the burning fuel, and after the heat exchanger through becomes clean air drying, again, non-pollution, fine grain and low cost is environmental protection equipment, the effect is remarkable, simple operation
Specifications:
|
Dimension (L*D*H) mm
|
2100×2080×8750
|
4500×3730×11260
|
|
Heat consumption(kj/kg)
|
5400
|
7400
|
|
Power(kw)
|
6.8
|
15.82
|
|
Average not uniformity
|
≤1
|
≤1
|
|
Dryer Net Volume(m3)
|
24
|
37
|
|
Heating Type
|
Low temperature cycling
|
Low temperature cycling
|
|
Capacity (kg/h) (water reduce ratio: from 25% to 14.5%)
|
1400~3500
|
1400~3500
|
|
Hot wind temperature(oC)
|
50-70
|
50-70
|
|
Utmost paddy temperature
|
34-43
|
34-43
|
|
Utmost paddy stock volume
|
12t
|
20t
|
|
Crack rate
|
≤3
|
≤3
|
|
