Specifications
mini tractor
1.20~165HP mini tractor
2.EPA,Emark certificate
3.With/without cab,2WD/4WD
20~80HP Mini Tractor
The mini tractor can be with various options:
1. 2WD/4WD
2. ROPS&Canopy/Cab with fan/Cab with heater/Cab with air-conditioning
3. Power steering/mechanical steering
4. Hydraulic output
5. Front/Rear ballast
When you inquire the tractor prices, please offer us the following information:
1. Your country
2. Power(HP) of the tractor, with or without cab
3. About how many units in your first order
4. Destination port

System
Clutch Single-function dry constant meshing
Gear Box 4)*(3+1)Sleeve gear shift
Main Drive One pair of spiral bevel gear
Differential Bevel gear
Differential Lock Sliding pin, foot operated
Final Displacement(L) Planeatry reduction gear
Travelling
Mechanism
Tyre Front 8.3-24
Rear 14.9-28
Steering Gear Hydraulic steering
Brake Oil immerszd multiplate disc
Working
Device
Hydraulic System
Lifting Capacity at 610mm Behind Lift Pioint (kg)1122
3-Point Suspension Category: II P. T. O
Shaft:Rotating
Speed (rpm):540/1000
Spline Size 6- 35Rectangular Spline
