         Multi Functional Fertilizer Spreader

Specifications
1.multifunctional:can sow seeds,spread fertilizer,cut weeds
2.small and exquisite
3.high efficiency
4.easy to operate
Application and Characteristics:
Fertilizing, weeding, scarification and other small scale seeding work for fruit gardens are characterized with the following:
1. Simple operation: Footplate motorcycle stepless speed changing (working when refueled and stopping when refueling stops), hand-operating clutch (clutch easy to be operated), and charging box clutch system with patent (the feeding stops right after gripping the handle;
2. Low in weight: The total weight is only about 60kg, which facilitate operation by females;
3. Multifunction: single and double ditch fertilizing and seeding, ditch digging, plowing, weeding and pesticide spraying can be realized.

External Dimension(mm)

1280X600X900

Weight(Kg)

About 58

Upward and Downward Positioning for the handrails

Adjustable

Attached Power System

168 gasoline engine

Starting Mode

manual

Fertilizing and Seeding Row Spacing

Adjustable

Type of Seeder Wheel (changeable)

3 holes, 4 holes, multi-holes

Coefficient of Variation for Seeding Evenness %

≤45

Coefficient of Variation for Total Fertilizer Feeding %

≤7.8
