Product Description
This combine harvester model is intended for reaping rice crop and wheat. The machine is capable of completing reaping, threshing, separating, cleaning and sieving in one smooth sequence. Due to its compact structure, high mobility, stability, reliability, economical value and strong accessibility to paddy fields, it is especially ideal for reaping crops in small and medium size fields(where stem is of 0.5~1.2 meter tall).
The tecnocial specification as belowed:
Total losses(%): Rice≤ 3.0
Lmpurity rate(%: ≤ 2.0
Breakage rate(%): ≤ 1.5
Reliability(%): ≥ 93
Cutting width(mm): 2300
Pure field capacity(ha/h): 0.17-0.40
Structure, Type: Full feeding, Self propelled, track
Weigh(kg): 2000-2200
Feed rate(t/h): 1.5-2.0
Dimensions at work, LxWxH(mm): 5260x2390x2320
Diesel engine horsepower(kw/rpm): 52/2600
Ground pressure(kpa): ≤ 24
Travel speeds: 6speeds forward, 2 speeds backward
Min. Ground clearance(mm): 260
Cleaning type: Double sieves + blower + re-thresher
Grain unloading method: Sacked & Auto unloading.
