Product Description
Main Performance for 4YW-3 Corn Combine Harvesters
Grain Loss Rate? <=2%
Broken Rate? <=1%
Qualified Rate of Cut Straw Length??? >=90%
Loss Rate of Ears? <=3%
Reliability??? >=95%
Specifications
Model? 4YW_3 Header Interchangeable Corn Combine Harvester
Size (Central Distance)? 700 Left /670 Right
Matched Motor??? >=60Hp
Productivity (Hectare/h)? 0.27-0.53
Forward Speed? 2.15_3.54 Km/h
Whole Quantity? 6400kg
Number of Working Lines? 3
Perfect Row Spacing 20? 600-700mm
Suitable Row Spacing? 550-850mm
Lowest Height of Ears??? >=500mm
Dimension (LengthxWidthxHeight)? 7860x2000x3600(mm)
Minimum Turn Radius? 5.2m
Cutter Type? Claw Type and Throw Falchion Type
Number of Claws? 12
Rotate Speed of Cutter Spindle? 1860 rev/s
Working Width of Back-to-the-field Machine? 1800mm
Spread Width of Back-to-the-field Machine? 1800-2000mm
Clearance apart from Land? >=300mm
Minimum Stubble Height? <=50mm
Grain Tank Capability? 1.8 Stere
Unloading Type? Hydraulic unloading
