Product Description
It adopts high air temperature to heat up food quickly in the top of the drying section, and take away part of the surface water; Intermediate drying air temperature off the middle section with large amounts of water; Through the above paragraph, after drying, the temperature of food grains has increased, so the bottom of the drying section can be achieved using low temperature food particles off in stronger adhesion of the water within it to avoid the purpose of grain temperature too high; Last through the cooling section of the full cooling, to achieve safe water and the temperature of food can be a machine Direct storage. The drying tower will be "downstream", "counter-current" use optimize drying process to achieve optimal results, the company is a fine grain drying tower models.
Characteristics of corn dryer
1. The grain dryer has huge handling capacity (100~1200 tons / day);
2. Large dehydrating range at a time. (3~16%);
3. This grain dryer adopts special air distribution, uniform drying;
4. Downstream drying, counter flow drying, downstream and counter flow cooling, more in line with precipitation patterns of food grain, low unevenness of grain moisture after drying (2%);
5. Piecewise air, multi-stage variable temperature drying, the color of dried food is good and biochemical indicators do not change;
6. With a unique design of double-row bucket grain technology, uniform flow of grain drying tower, no retention;
7. Machine insulation, high-intensity color plates with outsourcing, saving beautiful;
8. Waste heat recycling, reducing energy consumption.
Main technical parameters of Corn Grain Dryer
Type SNH5 SNH7.5 SNH10 SNH15 SNH20 SNH25
Processing capacity(t/day) 100 150 200 300 400 500
Drying rate (%) 4~16
Heating medium Clean Air
Hot blast temperature < 120
The maximum heating temperature of grain 55
Nonuniformity of drying (%) < 2
Fragmentation rate of value-added (%) < 0.5
Unit heat consumption(kj/kgH2O) 5800
Coal consumption (standard) (kg/h) 60~230 90~345 120~460 180~690 240~1000 300~1380
Installed capacity According to the environment, conditions, precipitation rate and the configuration
Host Dimensions (M) 2.5x2 2.5x2.5 3x2.5 4x3 4x4 5x4
Height of main machine (M) 24.8 25.4 26.3 27.2 27.8 28.4
